Select laser, fixture and stage according to actual product processing needs
One machine for drilling, cutting and scribing, reducing customer costs
Support full cutting / half cutting process
Single and double head, online, offline, automatic loading and unloading options, strong flexibility
Support multi-feature CCD visual positioning, with automatic compensation function
| Technical specifications | |
| Laser wavelength | 355nm, 532nm, 1064nm, etc. |
| Laser pulse width | Nanosecond, picosecond, femtosecond |
| Laser power | UV30W Max, Green60W Max |
| Laser Life | ＞20,000 hours |
| Product thickness | ≤2mm |
| Cutting Range | 350×400mm, can be customized |
| Processing speed | 800mm/s(Max.) |
| Platform Accuracy | Repeat ≤1μm, positioning ≤3μm |
| Positioning accuracy | ±5μm |
